Titanium Elbows
Standard: ASTM B363, ASME SB363, ASME B16.9, ANSI B16.9
Grade: Gr.1, Gr.2, Gr.3,Gr.7, Gr.9, Gr.12
Type: 45 Degree Elbows, 90 Degree Elbows, 180 Degree Elbows
R=1.0D, 1.5D, 3D, 5D
Seamless, Welded
SIZE: OD18-114.3 mm * WT 2.0-9.0 mm----SMLS pipe fittings
OD139.7-1220 mm * WT 2.0-30 mm----Welded pipe fittings
Technique: Welded, Forged, Rolled, Seamless
Non-standard products will be acc. to customer drawings to process.
Surface: Sand blasting, Pickling, Polishing.
Grade: Gr.1, Gr.2, Gr.3,Gr.7, Gr.9, Gr.12
Type: 45 Degree Elbows, 90 Degree Elbows, 180 Degree Elbows
R=1.0D, 1.5D, 3D, 5D
Seamless, Welded
SIZE: OD18-114.3 mm * WT 2.0-9.0 mm----SMLS pipe fittings
OD139.7-1220 mm * WT 2.0-30 mm----Welded pipe fittings
Technique: Welded, Forged, Rolled, Seamless
Non-standard products will be acc. to customer drawings to process.
Surface: Sand blasting, Pickling, Polishing.
More Details
Quality control testing: 100% X-ray detection (RT); 100% Surface penetration test (PT)
Price: Acc.to each unit, qty’ and other special request of clients.
Application fields: Chemical, Petroleum, Machinery, Industry etc.
